One-Stop Solution for Sintered Mesh
NAVI Titanium manufactures sintered wire mesh by stacking multiple layers of woven metal wire mesh and bonding them together through controlled high-temperature vacuum sintering. During the sintering process, contact points between the individual mesh layers form metallurgical diffusion bonds, transforming the separate layers into an integrated rigid porous structure.
Compared with conventional woven wire mesh, NAVI Titanium sintered wire mesh offers higher mechanical strength, better dimensional stability and improved resistance to pressure, impact and elevated-temperature operating conditions. The firmly bonded mesh layers help maintain a stable pore structure during filtration and processing, providing reliable structural performance for demanding industrial applications.
The filtration performance of sintered wire mesh is mainly determined by its filtration layer. Fluid passes through the interconnected openings within the metal mesh structure, while particles larger than the controlled opening size are retained on or within the filtration layer. By combining mesh layers with different wire diameters and mesh counts, sintered wire mesh can balance filtration accuracy, flow capacity and mechanical strength.
|
Standard Five-Layer Structure |
||||||||
| Filter Rating (μm) | Protection Layer | Filtration Layer | Separation/Distribution Layer | Reinforcing Layer | Supporting Layer | Air Permeability (L/min/m2) | Bubble Point Pressure (Pa) | Porosity (%) |
| 1 | 100 | 400 × 300 | 100 | 12 × 64 | 64 × 12 | 1.81 | 360-600 | 40 |
| 5 | 100 | 200 × 1400 | 100 | 12 × 64 | 64 × 12 | 2.42 | 260-550 | 40 |
| 10 | 100 | 165 × 1400 | 100 | 12 × 64 | 64 × 12 | 3 | 220-500 | 40 |
| 20 | 100 | 165 × 800 | 100 | 12 × 64 | 64 × 12 | 4.5 | 170-450 | 40 |
| 30 | 100 | 400 | 100 | 12 × 64 | 64 × 12 | 6.86 | 120-390 | 40 |
| 40 | 100 | 325 | 100 | 12 × 64 | 64 × 12 | 7.1 | 100-350 | 40 |
| 50 | 100 | 250 | 100 | 12 × 64 | 64 × 12 | 8.4 | 90-300 | 40 |
| 100 | 100 | 150 | 100 | 12 × 64 | 64 × 12 | 9.1 | 70-190 | 40 |
Note: Standard 5-layer sintered mesh typically weighs 8.4 kg/m² and has a thickness of approximately 1.77 mm.
Specific specifications can be customized according to your requirements and drawings.
Manufacturing Sintered Mesh
NAVI Titanium manufactures sintered mesh through a controlled production process that combines multiple layers of metal wire mesh into a single integrated porous structure. From material selection and mesh stacking to pressing, high-temperature sintering and final inspection, each stage influences the bonding strength, pore structure, filtration performance and mechanical stability of the finished product. The complete manufacturing process is illustrated below.
Purchasing Guide
If you want to choose a kind of sintered mesh, this is the guide for you.
Quotation
Do You Have Detailed Drawings or Specifications?
If yes, please provide your product drawings, dimensions, material requirements and quantities. Based on the provided information, NAVI Titanium can evaluate the manufacturing requirements and provide a quotation or Proforma Invoice.
If not, please refer to the following options 2 and 3.
Standard Sintered Mesh Specifications
Please refer to NAVI Titanium Sintered Mesh for the general specifications and related data. Please provide your application requirements, and the appropriate specification can be evaluated accordingly.
Customized Sintered Mesh Solutions
For customized requirements, NAVI Titanium can provide technical support based on product drawings, samples or application parameters.
Technology support: Assistance with material selection, mesh layer structure, filtration rating, dimensions and product configuration.
Custom Processing: Sintered wire mesh can be further processed through cutting, welding, rolling, stamping and other fabrication methods according to product requirements.
Non-disclosure agreement (NDA): Customer drawings, product specifications and technical information can be handled confidentially. Non-disclosure agreements are available when required.
Sample and Prototype Support
Samples are available for material evaluation, prototype development and application testing. For customized specifications, production feasibility and manufacturing requirements will be evaluated based on the product structure and technical parameters.
Standard Samples
Suitable for preliminary material and structure evaluation to verify basic performance.
Customized Samples
Available for prototype development based on drawings or specifications.
Small Batch Production
Suitable for product testing and pilot-scale projects before volume production.
RFQ Checklist
To help NAVI Titanium understand your requirements and provide an accurate quotation, please provide the following information whenever available. For customized sintered mesh, technical drawings, product photos or reference samples are also welcome. If some specifications are not yet confirmed, simply provide the available details and our technical team can help evaluate the suitable mesh structure and configuration.
| Information | What to Provide |
| Application | Filtration, separation, fluid distribution, gas diffusion, etc. |
| Filter Medium | Liquid or gas; medium name and composition |
| Filtration Requirement | Required pore size / filtration rating; flow rate or permeability, if specified |
| Material | SS304, SS316L, titanium, nickel, nickel alloy, or other specified material |
| Mesh Specification | Mesh count, wire diameter, opening size, or other mesh specifications, if known |
| Weave Type | Plain weave, Twill weave, Dutch weave, or other required weave |
| Layer Structure | 3-layer, 5-layer, multi-layer, or customized layer configuration |
| Operating Conditions | Operating temperature, pressure, differential pressure and flow rate |
| Product Dimensions | Length, width, diameter, thickness, or other required dimensions |
| Product Form | Sheet, plate, disc, tube, cartridge, or custom shape |
| Connection / Fabrication | Threads, welding, bending, cutting, machining, edge treatment, or other requirements |
| Quantity | Sample quantity and estimated production quantity |
| Drawing / Sample | Technical drawing, 3D file, reference sample, or product photo |
Why Choose NAVI Titanium?
NAVI Titanium Core strengths
Integrated Manufacturing Capability
From mesh selection and layer design to sintering and secondary fabrication.
Custom Manufacturing
Support for customized dimensions, layer structures and fabricated components.
Quality & Certification Support
Manufacturing and quality control are managed under an ISO 9001 quality management system.
Export Packaging
Protective packaging designed to help prevent damage and contamination.
